| Brand Name : | Yeoan |
| Model Number : | FH1755B |
| Payment Terms : | L/C, T/T, Western Union |
| Delivery Time : | 15 days |
Highlights:
• Long-life laser light source (25,000 hours in green mode)
• Sealed light source (IP65) to prevent dust intrusion, avoid dust
causing brightness loss and color unevenness
• Sealed internal circulation intelligent cooling system with
built-in independent cooling system, TEC + air cooling technology
• HDMI, DVI, 3D Sync, VGA input supports 120Hz 3D
• With vertical and horizontal keystone correction and four-corner
correction functions
• Standard support for HDBaseT long-distance network transmission
function
• Support horizontal and vertical 360° rotation installation
• Support Crestron, P-Link
• Support high altitude mode (below 5000Meters)
• Quick power on and off function, power off protection function
• Electric zoom, electric focus
• Extreme color technology (DLP™)
• Can be used in an environment with a temperature of 5°C-35°C
| FH1733B | FH1755B | |
| Chip size | DLP(0 . 67"DM D) | |
| Physical resolution | WUXGA (1920x1200) | |
| Brightness (lumens* 2 ) | 13300 | 15500 |
| Uniformity* 2 | 90% | |
| Contrast* 2 | 1,500:1 Static 30,00000 : 1 Extreme Black | |
| Light source life | 20000H, Green Mode 25000H | |
| Throw ratio (standard mirror) | 1.22-1 . 53 / 1.2-2 . 0 | |
| Alternative lenses | 0.3 I 0 . 36 I os I 0 . 6 I 0 . 7 I 0.51-0 . 65 / 0.65-0.76 / 0 . 75-0 . 95 / 0.95-1 . 22/1.52-2.92/2 . 9-5.5 / 5 . 5-9.3 | |
| Focus Circle | 70~400 inch | |
| Zoom/focus mode | Manual/electric zoom | |
| Range of movement | about : 60% ． up and down: 100% | |
| Color Space | 110% REC709 | |
| Keystone Correction | Level: Earth 25° vertical : earth 30° | |
| Aspect Ratio | 16 : 10 (4:3 , 16:9 , 16 : 10 , 16:6) | |
| Cooling method | TEC +Liquid cooling +Air cooling technology | |
| Projection method | Front projection / rear projection / desktop / ceiling mount | |
| Power consumption | Working power : 1 250W +/-10% , Standby power consumption : ＜ 0 . 5W | |
| Menu language | Chinese, English, Traditional Chinese | |
| Product noise | Normal : 45dB, Eco: 36DB | |
| Operating altitude | 4000M the following | |
| Operating temperature | 5-35° | |
| Storage temperature | 20°c arrive 60°C | |
| net weight | 35KG | |
| Dimensions (width x high x deep) | 525mm*580mm*244mm (without lens) | |
| Signal interface | VGA IN/OUT X1, DVI X1, HDM I X2, HD BASET X1, S-video X1, USB : X1(Out : 5V/ 1 .5A(M AX)) Video X1, Audio IN/ Out X1, BNC: X5(Format:RGBHV/YPBPR/YCBCR), AC IN X1 | |
| Control interface | 3D SYNC X1, Mini USB X1(Download FW), RS232 input/Output X1, LAN control (R45 ) X1 | |
|
|
